Toyota Hilux 2.4 D Engine Technical Data

Engine type - Number of cylinders : Inline 4

Engine Code : -

Fuel type : Diesel

Fuel System : Direct Injection.

Engine Alignment : Longitudinal

Engine Position : Front

Engine size - Displacement - Engine capacity : 2393 cm3 or 146 cu-in

Bore x Stroke : 92.0 x 90.0 mm

3.62 x 3.54 inches

Number of valves : 16 Valves

Aspiration : Turbo (TGV) + Intercooler

Compression Ratio : 15,6

Maximum power - Output - Horsepower : 150 PS or 148 bhp or 110 kW @ 3400 rpm

Maximum torque : 400 Nm or 295 lb.ft @ 1600-2000 rpm

Drive wheels - Traction - Drivetrain : AWD

Transmission Gearbox - Number of speeds : 6 speed Manual

Toyota Hilux 8 Double-Cab 2.4 D-4D 150HP 4x4 Performance

Top Speed : 170 km/h or 106 Mph

Acceleration 0 to 100 km/h (0 to 62 mph) : 13.2 s

Toyota Hilux 8 Double-Cab 2.4 D-4D 150HP 4x4 Size, Dimensions, Aerodynamics and Weight

Body : Pick Up

Num. of Doors : 4

Wheelbase : 308.5 cm or 121.46 inches

Length : 535 cm or 210.63 inches

Width : 185.5 cm or 73.03 inches

Height : 185.5 cm or 73.03 inches

Front Axle : 153.5 cm or 60.43 inches

Rear Axle : 155 cm or 61.02 inches

Ground clearance : 29.3 cm / 11.54 inches

Ground clearance : 29.3 cm / 11.54 inches

Approach angle (deg) : 31.0°

Departure angle (deg) : 26.0°

Num. of Seats : 5

Aerodynamic drag coefficient - Cx : -

Front Brakes - Disc dimensions : Vented Discs (- mm)

Rear Brakes - Dics dimensions : Drums (- mm)

Front Tyres - Rims dimensions : 265/65 R17

Rear Tyres - Rims dimensions : 265/65 R17

Front Wheels Width : 7,5"

Rear Wheels Width : 7,5"

Curb Weight : 2125 kg OR 4685 lbs

Weight-Power Output Ratio : 14.2 kg/hp

Trunk / Boot capacity : - L

Steering : Rack and pinion Hydraulic

Front Suspension : Coil springs.

Rear Suspension : Beam axle
